CV-5200 series intelligent welding table (Connection Validation welding table). The thickness of metal compounds is crucial for the formation of solder joints. Welding Effect Verification (CV) evaluates the quality of solder joints by calculating the formation of intermetallic compounds and provides closed-loop feedback to operators.

CV provides feedback to the operator through an integrated LED halo on the handle. He takes on the task of judging the quality of welding, so that operators do not have to subjectively judge the quality of welding.

CV extends the operator's skill in assessing the quality of solder joints by introducing objective methods to determine the quality of solder joints. This system's objective method achieves repeatable welding processes and provides a measurable standard for the welding process.

CV-5200 series intelligent soldering station features and advantages:

1. Only heating technology can be used for on-demand heating

2. Verification technology for the formation effect of patented metal compounds

3. 2.8 "color touch screen

4. Possess communication interfaces for process data traceability and firmware upgrades

5. Accurate display of soldering iron tip temperature

6. Power can be collected by a built-in power meter and displayed on the success rate curve of the LCD screen

7. Patented soldering iron tip with built-in chip technology

① Closed loop bidirectional communication

② Store and record soldering iron tip information

③ Provide traceable information

④ When using incompatible soldering iron tips, the host will be protected

⑤ Compatible with MX series power hosts

8. Password protection function

When good solder joints are formed, the LED light strip on the handle will send a signal to the operator.

10. The large screen displays information such as the temperature of the soldering iron tip.

The CV-5210 soldering station includes:

1. CV power host

2. CV-H1-AV: Advanced soldering handle integrated with LED light strip

3. MX-W1AV: Handle holder that can extend the lifespan of soldering iron tips

CV-5200technical specifications

With the launch of the new CV-5200 series intelligent soldering station that can verify the soldering effect, Metcal has also introduced a new intelligent numbering scheme for soldering tips aimed at helping customers choose the appropriate soldering tip model to replace the old one.

Soldering iron tip&heating element series

Iron Tip Series

1. CVC - verifiable soldering effect soldering iron tip, with the function of verifying soldering effect

2. SMC - Surface mount soldering iron tip

3. The new series of soldering iron tips is about to be launched on the market

Heating element series - determined by the X of the soldering iron tip model

?5-500Series heating element

?6-600Series heating element

?7-700Series heating element

?8-800Series heating element

?9-900Series heating element
